The top unit, below, houses the Super 8 and Super 3 in an upward firing direction.  The bottom is fixed to the top by 9 posts measuring an inch square and about 5 inches in length.









The top unit on a 6.5 ft^3 corner bass reflex.

More on that which is in the pic can be found on the Co-Axial 12 page.
